Thread Milling Pratt and Whitney C 6" x 60"
The Pratt & Whitney C 6" x 60" Thread Milling Machine is a specific model designed for thread milling operations on work pieces with dimensions up to 6 inches in diameter and 72 inches in length. Pratt & Whitney machines are known for their precision engineering and high-quality construction. The C 6" x 60" model would likely offer tight tolerances and excellent repeatability, crucial for thread milling operations.
Description:
Machine Type:Thread Milling Machine
Machine Make:Pratt & Whitney
Machine Model: C 6" x 60"
Features: Rigid Construction, Stability & Accuracy.
Technical Specifications:
| Max Work Diameter | 6" |
| Length Between Centers | 72" |
| Depth of Cut, Maximum | 11/16 |
| Lead of Regular Gears (LH)/(RH) | 24 PI to 24" / 24 PI to 18" |
| Hole Thru Spindle | 4 -1/32" |
| Spindle Collet Capacity | 4" |
| Cutter Size | 3.25" and 4" with 1" Hole |
| Work Speeds | (21) 140 to 5 RPM |
| Cutter Spindle Speed | (8) 113 to 452 RPM |
| Cutter Spindle Motor | 3 HP |
| Work Spindle Drive | 1.5 HP |
For sale in Delhi,Used Thread Milling Pratt & Whitney in excellent working condition at a very reasonable price.
