Union BFT 80/2 Horizontal Boring
WMW Union BFT 80/2 Horizontal Boring is a reliable and sturdy machine that is perfectly suitable for heavy-duty drilling and boring operations.
Horizontal Boring Machine WMW Union BFT 80/2 has a spindle diameter of 80 mm with 1250 mm table cross travel, 1250 mm vertical head travel, 710 mm Spindle travel, large size T slotted 360 degree rotary 1410 x 1250 mm table enables the WMW Union Boring BFT 80/2 to machine mid size jobs quite easily and comfortably. This machine is also completely suitable to be used for large work pieces with utmost precision & efficiency.
Description:
Features:
Easy Installation, Pocket friendly prices, Minimum Maintenance.
Technical Specifications:
| Digital Read Out | Anilam |
| Facing Head Diameter | 520 mm |
| Facing Head Slide Cross Traverse | 180 mm |
| Feed Rate | 0.003 - 20 mm / Min |
| Head Stock Vertical Traverse (Z) | 1150 mm |
| Input | 415 V / 3 Ph / 50 Hz / 7.5 KW |
| Spindle | 80 mm |
| Facing Speeds | 8 - 200 RPM |
| Spindle Speeds | 250 - 1600 RPM |
| Spindle Taper | 5 MT |
| Spindle Traverse | 700 mm |
| Table Cross Traverse (X) | 1250 mm |
| Table Longitudinal Traverse (Y) | 2000 mm |
| Table Size | 1410 mm x 1250 mm |
| Table Swivels | 360 Degree |
Buy used Union BFT 80/2 Horizontal Boring invery good working condition at a very competitive price.
