WMW FZWD 160 Facing Centering Machine
The WMW FZWD 160/1000 is a facing and centering machine manufactured by WMW (Werkzeug maschinenfabrik Wema Glauchau GmbH) used in metal working.
It is designed for facing and centering operations on cylindrical workpieces. The specifications "160 x 1000" typically indicate the maximum diameter and length of the work piece that the machine can accommodate.
Description:
Machine Type: Facing and Centering Machine
Machine Make: WMW
Machine Model: FZWD 160
Features: Precise & accurate, minimum maintenance.
Technical Specification:
| Feed Range | 1-4000 mm/min |
| Turning Speed Range | 20-10500 U/min |
| Max Work Piece Diameter | 160 mm |
| Max Work Piece Length | 1000 mm |
| Rapid Traverse | 24 m/min |
| Total Power Requirement | 18 KW |
| Number Of Spindles | 4 |
| Spindle Speeds | Milling Spindles 112-224 RPM |
| Drilling Spindles | 560 - 1400 RPM |
| Machine Dimension (L/W/H) | 3 x 1.97 x 2.25 m |
| Weight Approx | 3500 Kg |
Buy Used Imported WMW FZWD 160 Facing & Centering Machine in an excellent working condition at a reasonable price.
